CATIA V5 Foundations for Aerospace Part Designers
This course will introduce you to CATIA V5. It will first teach you how to create simple models from 2D sketches, and then the correct techniques for the creation and annotation of complex solid models. It will also introduce you to surface design and the concepts of part design in the context of an assembly
- Level
- Fundamental
- Length
- 36 hours
- Product
- CATIA V5
- Delivery
- Instructor-led or eLearning
What you will learn
- Identify the appropriate CATIA V5 tools used for part design
- Plan the construction of a complex part in order to properly convey its visual and functional aspects
- Annotate parts
- Design simple surface parts
- Modify a part within the context of an assembly
Topics covered
- Introduction to CATIA4 hour
- Creating Profiles3 hour
- Creating Basic Features3 hour
- Creating Additional Part Features4 hour
- Creating Dress-up Features4 hour
- Reusing the Data2 hour
- Designing Complex Parts5 hour
- Finalizing Design Intent5 hour
- Working with Surface Design2 hour
- Designing in Context1 hour
- Master Exercise: V5 Aerospace Part Design3 hour
Who it is for
Aerospace Part Designers
Prerequisites
Learners attending this course should be familiar with Mechanical Design and the Windows Operating System.
Software: Mechanical Design 2
