CATIADesign and Engineering
Generative Part Structural Analysis Expert
This course will teach you how to use advanced Finite Element Analysis pre-processing techniques and post-processing tools, including the concept of defining virtual parts to avoid excessive geometric modeling. You will learn how to perform frequency analysis on a single part, and how to use adaptive meshing to achieve pre-defined accuracy
- Level
- Fundamental
- Length
- 7 hours 35 minutes
- Product
- CATIA V5
- Delivery
- Instructor-led or eLearning
What you will learn
- Define and customize the material properties of the parts to be analyzed
- Apply pressure, acceleration and force density loads
- Define virtual parts to simplify the analysis
- Apply pivot, ball-joint and user-defined restraints
- Compute frequency analysis for a single part
- Create planar sections to visualize the internal result values
- Compute and refine a mesh using adaptive meshing in order to achieve the pre-defined accuracy
Topics covered
- Introduction to Advanced Pre-Processing Tools2 hour 30 min
- Introduction to the Frequency Analysis30 min
- Introduction to the Computation2 hour
- GPS Advanced Post-Processing Tools2 hour
- Master Exercise: Frequency Analysis35 min
- Assessment: Generative Part Structural Analysis Expert-
Who it is for
Mechanical Designers
Prerequisites
Learners attending this course should have completed the CATIA V5 Fundamentals and Generative Part Structural Analysis Fundamentals courses
Software: Mechanical Design Configuration 2, GPS
