Practice CATIA Piping and Tubing Systems Design
This module will teach you how to create piping and instrumentation diagrams (P&ID). You will learn how to place an equipment in the diagram with multiple graphic representations. You will also learn how to connect them and place in-line components. Finally, you will learn how to add annotations, review the design and make the necessary modification.
- Level
- Fundamental
- Length
- 4 hours 30 minutes
- Product
- 3DEXPERIENCE Platform
- Delivery
- Instructor-led or eLearning
What you will learn
- Route pipe or tube lines
- Position piping or tubing parts and equipment
- Adjust the design of a piping or a tubing network
- Validate the piping and tubing design
- Prepare the piping and tubing design for manufacturing
Topics covered
- Introduction to the CATIA Piping and Tubing Systems Design25 min
- Preparing the Data Setup30 min
- Modifying the Piping and Instrumentation Diagram1 hour
- Creating and Placing New Components in a Diagram45 min
- Creating a New Diagram25 min
- Reviewing the Diagram25 min
- Annotating the Diagram30 min
- For Administrators: Building the Customized Setup30 min
Who it is for
Piping or Tubing Schematic Designers
Prerequisites
Students attending this learning module should have completed the Explore the Collaborative Business Innovator Role module.
Software: 3D Swymer (IFW-OC), Collaborative Industry Innovator (CSV-OC), Fluid 3D Systems Designer (FLG-OC) and Systems Schematic Engineer (TIC-OC).
